Description
| General feature | |
|---|---|
| Power Handling (RMS) | 1200 W |
| VC diameter / material | 2,8″ round copper |
| VC wire insulation | Polyimide |
| Frame material | Steel |
| Magnet size and q-ty | 170*26mm x 2 pcs / 6,69*1,02″ x 2 pc |
| Spider diameter and q-ty | 193mm x 4 pcs / 7,6″ x 4 pcs |
| Cone material | Paper with glass fiber |
| Dust cap material | Hi-temp ABS |
| Parameters | |
| DC Resistance (Re) | 1,8+1,8 Ω |
| Free Air Resonance (Fs) Hz | 33,1 |
| Moving Mass (Mms) g | 238 |
| BL Tm | 18,6 |
| Total Speaker “Q” (Qts) | 0,48 |
| Electrical Q (Qes) | 0,53 |
| Mechanical Q (Qms) | 5,2 |
| Equivalent Compliance (Vas) L | 16,5 |
| One-Way Linear Excursion (Xmax) (BL 50%) mm | 19 |
| Sensitivity (1 W / 1 m) dB | 83,7 |
| Effective Piston Area (Sd) cm² | 337 |
| Physical Specifications | |
| Overall Diameter | 275mm / 10,83″ |
| Mounting Hole Diameter | 242mm / 9,53″ |
| Mounting Depth | 157mm / 6,18″ |
| Driver Displacement | 2 l / 0,53 Gal |
| Net Weight | 10 kg / 22,05 lbs |
