Description
Technical specifications:
– Operation Class: D
– Number of Channels: 01
– Maximum Power:
@ 14.4 VDC – 0.5 OHM: 8000W RMS
@ 14.4 VDC – 1 OHMS: 8000W RMS
@ 14.4 VDC – 2 OHMS: 8000W RMS
@ 14.4 VDC – 4 OHMS: 4800W RMS
– Input Sensitivity: 4V ~ 0.2V
– Signal to Noise Ratio: >90dB
– Frequency Response: (Full Range): 8Hz to 200Hz(-3dB)
– Crossover High Pass (HPF): Variable 8Hz to 30Hz (-12dB / 8th)
– Crossover Low Pass (LPF): Variable 60Hz to 200Hz (-12dB / 8th)
– Bass Boost: 35Hz ~ 55Hz, 0 to +10dB
– Efficiency: 78% @ 0.5 Ohm | 82% @ 1 Ohm | 86% @ 2 Ohms
– Input Impedance: 10K OHMS
– Protection System: Output short-circuit, low/high supply voltage and Thermal protection
– Minimum Supply Voltage: 9VDC
– Maximum Supply Voltage: 17VDC
– Idle Consumption: 5.0A
– Musical Consumption @ 14.4VDC: 356A @ 0.5 Ohm | 339A @ 1 Ohm | 323A @ 2 Ohms
– Rated Power Consumption: 712A @ 0.5 Ohm | 678A @ 1 Ohm | 646A @ 2 Ohms
– Dimensions (W x H x D): 9.37″ x 2.80″ x 20.16″ inches
– Weight: 16.39 lb
