Description
- The power supply circuitry adopts advanced pulse width modulator integrated circuits that are designed to offer improved performance and efficiency.
- Designed with Advanced HEXFET® Power MOSFETs from International Rectifier that utilize advanced processing techniques to achieve extremely low on-resistance and reliable fast switching speed.
- Premium Toroidal Transformer for optimal electrical efficiency and minimal signal distortion.
- Premium Low ESR capacitors for minimal power loss and reduced internal heating.
- Precision metal potentiometers for precise tuning and sturdy construction
- Features 500V Class X2 capacitors with self-healing properties for high-frequency, high-current protection, ensuring low-loss AC peak surge and MOSFET protection.
- High-efficiency Ferrite Core Inductor power output filters provide low current eddy losses over frequencies with high permeability.
- High-performance class D intelligent driver IC with PWM modulator and protection with HEXFET Power MOSFET for abundant power and high efficiency.
FEATURES
- High/Low Input Modes
- GTO™ Signal Sense
- Linkwitz-Riley Crossovers
- Start-Stop Compliant
- High Power Output in a Sleek Chassis
- ParaBASS® Low Frequency Contouring
- Valet Mode Option
- Optional Remote Level Control (ACR-1)
- EV Compliant up to 17V
- Spike Mode Enabled
SPECIFICATIONS
INPUTS
- Preamp Inputs: 2
- Line-Level Inputs: 6 V max
- Speaker-Level Inputs: 20 V max
OUTPUTS
- Rated Continuous (RMS) Power at 14.4V:
- 400W x 1 @ 4Ω
- 600W X 1 @ 2Ω
- 800W x 1 @ 1.33Ω
Remote Level Control
- ACR-1 (optional)
WEIGHTS & DIMENSIONS
- DIMENSIONS: 10.9” W x 6.7” D x 2.1” H
- WEIGHT: 6.05 lbs
PERFORMANCE
- S/N Ratio (ref: rated power): 110.2 dBA
- THD+N: <0.14%
- Power / Ground Wire Gauge: 4 AWG
- Recommended Fuse rating: 100A
- Valet Mode: Yes
- Subsonic Filter: Variable
- Linkwitz-Riley X-Over:
-
- Low Pass
- Freq. Range: 60 Hz to 120 Hz
- Bass Processing: ParaBASS®
